Discover the N32H meter, which combines versatility, modern design, and reliability.
This solution is designed for the most demanding applications:
✔️ Perfect for measurements of of DC circuit parameters.
✔️ Modern, two-line display – exceptionally clear and user-friendly.
✔️ RS-485 digital output – compliant with the popular industrial communication standard.
- voltage measurement ±600V (maximum range display ±1200 v), current measurement via shunt, power, energy and capacity measurement of d.c. circuits
- two-line LCD display with high contrast and built-in backlighting
- possibility of displaying the measured value and time simultaneously or an second measured value or unit (automatically displayed unit of measured quantity)
- wide range of voltage measurement at the shunt input up to 1500 mV
- high sampling frequency of measured signals
- programming parameters via buttons or rs-485 interface and free e-con software
- 4 alarm outputs with signaling on led diodes, working in 7 different modes (option)
- pulse output to control energy consumption
- conversion of any measured value into an analog signal 0/4...20 mA or 0...10V (option).
- memory of minimal and maximal values for all measured quantities.
- automatic voltage measurement compensation function alarms
- overall dimensions: 96 x 48 x 93 mm.
